1 GE EPon GPon XPon ONU com porta Ethernet de 1 Gigabit

1 porta GE EPon GPon XPon ONU 1GE LAN RJ45

Stock:

Brand: Hosecom-PON Products

SKU:{{ product.sku }}

Model: {{ product.model }}

User Rating:

Product Details Reviews(0)

1 porta GE EPon GPon XPon ONU 1GE LAN RJ45

Visão geral

1 GE EPon GPon XPon ONU X11 é uma das mais recentes séries de terminais de comunicação de rede óptica passiva G / EPON, o produto fornece 1 interface RJ45 10/100 / 1000M, 1 acesso de fibra óptica, adequado para usuários domésticos e de pequenas empresas, pode atender bem à alta velocidade FTTH aplicações de transmissão de dados.

Função de interface 1 GE EPon GPon XPon ONU

1 * interface G/EPON: interface SC/UPC/APC, em conformidade com os padrões GPON e EPON
1 * interface Ethernet: 10 Mbps/100 Mbps/1000 Mbps, RJ-45, em conformidade com os padrões IEEE802.3-2005

1 GE EPon GPon XPon ONU

1 GE EPon GPon XPon ONU Hardware Parameters

LED	PWR+PON/LOS+LAN
Port	1*RJ45(GE)
	1*Reset
	1*SC/APC (or SC/UPC)
	1*DC
Size	79.574.722mm(LWH)
Power Consumption	≤8W
Ethernet Port	Ethernet port-based VLAN tags and tag removal
	VLAN transparent and aggregation
	MAC address learning
	10/100/1000Mbps Auto negotiation

Solfware Parameters

G/EPON	ITU-T G.984.1-4
	IEEE 802.3ah
	15 TCONTs /256GEM ports
	8 Egress queues per TCONT at least
	VLAN or VLAN plus priority gem mapping mode
	SN/LOID/SN+ Password authentication
	Performance monitoring: eth/Gem port
	Dying gasp
Layer 2 Features	MAC learning (SVL)/aging
	Support max frame length to1518 bytes
	VLAN tagging for untagged packets
	Support VLAN 1-4094
	VLAN transparent/translation
Multicast	IGMP v2 (RFC 2236) and IGMP v3 (RFC 3376)
Multicast	IGMP snooping
Management	OMCI/Web UI
	SSH management with CLI commands
	Dual-system software backup and rollback

Environment

Operate Temperature	0℃~45℃
Storage Temperature	-20℃~70℃
Operating Humidity	5%～95% non-condensing
Power Supply	12V/0.5A
