O G1412C é uma unidade terminal óptica adaptativa de modo duplo GPon e EPon altamente integrada com Wi-Fi 5 AC1200 de frequência dupla. Ele suporta acesso de largura de banda ultra larga por meio da tecnologia upstream GEPon e oferece aos usuários a função WiFi básica, roteamento e função Ethernet gigabit. As portas de rede upstream do G1412C são portas GEPon. Ele tem 4 portas GE RJ45, 1 porta USB, 1 porta VoIP e porta WiFi 5 WLAN. Ele tem interface CATV para fornecer acesso à TV do cliente.
| Hardware Parameters | |
| PORTS: | 4*RJ45(GE) |
| 1*RJ11(POTS) | |
| 1*Reset+1*Power +1*LED | |
| button+1*WiFi button+1*WPS | |
| 1*SC/UPC (or SC/APC) | |
| 1*POTS | |
| 1*DC | |
| 1*CATV | |
| 1*USB2.0 | |
| Size | 190mm*135mm*33mm(L*W*H) |
| consumption | ≤8W |
| LED | POWER+PON/LOS+NET+LAN+POTS+WiFi+WPS+USB |
| Interface Parameters | |
| G/EPON Port | GPON: Class B + |
| EPON: PX20+ | |
| GPON: Upstream1.25Gbps | |
| Downstream: 2.48Gbps | |
| EPON: Upstream1.25Gbps; | |
| Downstream: 1.25Gbps | |
| Ethernet Port | Ethernet port-based VLAN tags and tag removal |
| VLAN transparent and mark | |
| MAC address learning | |
| 10/100/1000Mbps Autonegotiation | |
| VolP Port | Call waiting, Inconditional Call Forward |
| Call Forward if Busy,Call Forward if no reply and Three-party calls. | |
| G711A/G711U/G729/G722 | |
| SDP protocol (RFC 2327 and RFC 4566) | |
| T.30/T.38/G.711 faxmode | |
| WiFi5 | |
| WiFi protocol | 2.4GHz supports 802.11b/g/n |
| 5GHz supports 802.11a/n/ac | |
| Transmit power | 2.4G 100mW,5G/200mW |
| Antenna gain | 5dBi |
| Antenna | dual-antenna MlMO (2.4G&5G) |
| WLAN penetrate | one reinforced concrete wall or two ordinary brick walls (non-reinforced concrete) |
| WLAN access capability | 64 client |
| channel | 2.4GHz(channel 1-13), 5GHZ(channel 36-161 ) |
| WPS | WLAN terminal devices with WPS, Push Button function establish connection within 2 minutes |
| WLAN security function | WPA-PSK, WPA2-PSK, WPA3, WPA-PSKNPA2-PSK, AES, AES+TKIP |
| Wifi rate | 2.4G 300Mbps , 5G 867Mbps |
| CATV | |
| Remote control CATV | ON/OFF |
| optical AGC | -10~+2dBm |
| Output level | 76dBuV |
| RF bandwidth | 47-1000 MHZ |
| In band flatness | +1.25dB |
| Qutput return loss | >12dB |
| CATV system parameters | C/N:> 43dB , C/CTB :≥55dB, C/CSO >55dB, MER ≥32dB, BER ≤1*10E-6 |
| Environment | |
| Operating Temperature | 0℃~45℃ |
| Storage Temperature | -20℃~70℃ |
| Operating Humidity | 5%~95%(non-condensing) |
| Power Supply | 12V/1.5A |
